SYRIDE Sys’Nav XL
Sys’Nav XL: compact technology!
Simple, light and efficient.
A new generation screen:
This is the first thing you’ll notice when you’ll take a SYS'Nav XL in your hands! 30% larger than its little brother’s,
the 2.7'' screen has an active matrix reflective technology similar to the one used in the SYS'Evolution.
The advantages for the pilot:
- Optimum readability outdoors (the more sun, the more contrast)
- Lower consumption (80% less than a traditional screen and no need for
Moreover, the resolution of the screen (400x200 pixels) has been dramatically
improved (22 times more precise than the SYS'Nav V3 screen) with a spacing
between each pixel of 0.147mm (by comparison, it is 0.152mm on the
SYS'Evolution). The pilot can display more information and details on the same
screen. The display is also more pleasant to the eye.
14 days for return
A more powerful speaker than on the SYS'Evolution:
Integrating a loudspeaker to find the same kind of sound as on the SYS'Evolution was complex. We wanted to
keep an output on the front face which allows to avoid losses. In spite of the bigger screen, we managed to put
a 1 Watt speaker (0.5 Watt on the SYS'Evolution) while respecting the manufacturer's recommendations to
obtain the most perfect sound possible!
The pilot will thus have the pleasure to hear the sound of a more harmonious and softer vario. Custom
configuration is always possible with our online too.
Versatile Bluetooth connectivity:
With our experience in the connectivity of the SYS'Evolution, it was difficult to imagine a new instrument
without Bluetooth. It remains for us the best compromise to connect to the internet and use peripherals on a
Here is an overview of pilots will be able to do with Bluetooth:
- Live tracking on syride.com : https://www.syride.com/en/live (with Syride application using GPS data
from the instrument)
- Send your flights automatically to your Syride profile as soon as you land and upload your IGC file to
contests (via Syride application)
- Get inflight wind reports on your instrument
- New : Scan the QR Code of a navigation route to send it in the SYS'Nav XL (via Syride application)
- New : Share Vario and GPS data with 3rd party application (such as XCTrack or FlySkyHy) to save battery
of your phone/tablet Currently only working with XCTrack
- New : Connect to external peripherals… More info to come later!
Expected for its simplicity of use and its reversibility, the SYS’Nav XL has now a USB type C plug. A new plastic
injection mold had to be produced to support these new evolutions (screen, speaker, USB...).
The file management has also been completely revised! It will be possible to communicate with the SYS'PC TOOL
software as before, but also to access the flight data (IGC files) as if a USB disk had been connected.
The pilot gains in convenience, he will be able to use his existing phone or action cam cable to connect the
instrument and will not have to use the SYS'PC Tool software to access the flight files
A more powerful battery and a dedicated charge manager:
The surface of the electronic board has been reduced to accommodate a battery with a capacity 40% higher
than the SYS'Nav (850mAh against 600mAh), it is essential to meet the needs of the very energy-hungry
speaker. It is the level of the sound volume and the activation of the sink sound that will have the most impact
on the battery life of the SYS'Nav XL!
The addition of a dedicated charge manager allows to have a very precise state of the battery charge value.
Voltage variations will not affect the displayed information.
Thinner Velcros and featherweight:
New thinner and lighter velcros have been adopted on the SYS'Nav XL for its attachment (risers or cockpit).
Despite the addition of new technologies, the instrument is now thinner and lighter than a SYS'Nav V3 by
10%! It weighs only 81gr including the attachment system.
New Syride Mobile App
This new app will soon be available on Android and Apple and will perform several functions:
1) Connect your SYS’Nav XL to the internet
2) Setting up your SYS’Nav XL
3) Create a route from your mobile phone
4) Pair multiple devices simultaneously to the SYS’Nav XL
Function : Alti-Vario-GPS with G-force meter
connectivity : Bluetooth
Size : 10cm x 6.1cm x 1.7cm
Weight : 81gr
Topography : Worldwide
Road map : Worldwide
Airspaces : Worldwide
Screen : 2.7 inch high contrast 240x400 pixels
Volume : 4 levels & OFF position
Autonomy : From 10 to 40h
Memory : 2000h flight (1pt/sec)
Waypoints : 25 000
Routes : 200 routes of 150 waypoints max
Output files : IGC, GPX and KML
Online flightbook : included
Risers fixing : included
Thermal sniffer : activable from -0.1m/s to +0.1m/s
Instant vario : Yes via 3-Axis Accelerometer
weather station : Yes via configurable screen
